Available Pumps
| Pump Type |
Pump Series |
Displ. Range cu. in. (cm3) |
Flow Range GPM (LPM) |
Max. Pressures PSI (BAR) |
Maximum RPM |
Product Brochure |
Service Manual |
|---|---|---|---|---|---|---|---|
| Std Gear Pumps | PF | .24-2.01 (4-33) | 1-8.7 (4.33) | 2700-4000 (186-276) | 2200-4000 | MP98-02 | SP98-02 |
| PH | .62-2.48 (10-41) | 3-11 (10-41) | 2000-3500 (138-241) | 3000-3500 | N/A | SP98-02 | |
| PK & PKS | .98-3.94 (16-65) | 4-17 (16-65) | 2500-3000 (172-207) | 2500-3600 | MP89-12 | SP98-02 | |
| PM | 3.18-7.01 (52-115) | 14-30 (52-115) | 2000-3000 (138-241) | 2500-3000 | MP89-13 | SP98-04 | |
| 6.1-9.27 (100-152) | 27-40 (100-152) | 2500-3000 (172-207) | 2500-3000 | N/A | N/A | ||
| Clutch Pumps |
PF | .24-2.01 (4-33) | 1-8.7 (4-33) | 2700-4000 (186-276) | 2200-4000 | MP93-03 | SP98-02 |
| PF2 | .43-1.74 (7-28) | 1.8-7.5 (7-28) | 2000-4350 (138-300) | 2500-3000 | N/A | ||
| PH | .62-2.48 (10-41) | 3-11 (10-41) | 2000-3500 (138-241) | 3000-3500 | MP89-14 | SP88-02 | |
| Dump Pumps |
S2/S3/S4/S5 | 1.47-3.45 (24-57) | 6-15 (24-57) | 2500 (172) | 2500 | MP93-01 | SP88-02 |
| E2/E3 | 5.2-6.37 (85-104) | 23-37 (85-104) | 2500 (172) | 2500 | MP94-01 | SP89-03 | |
| EH2/EH3 | 4.95-8.25 (81-135) | 22-36 (81-135) | 2500 (172) | 2500 | MP94-01 | SP89-03 | |
| Refuse & Specialty Gear Pumps |
MLSA | 1.41-5.3 (23-87) | 6-23 (23-87) | 2500-4000 (172-275) | 2300-3600 | MP92-07 | SP93-02 |
| Power-Miser "L" | 3.18-5.73 (52-93) | 14-25 (52-93) | 2500-3000 (172-207) | 2500-3000 | MP92-05 | SP99-02 | |
| Power-Pro "L" | 3.18-5.73 (52-93) | 14-25 (52-93) | 2500-3000 (172-207) | 2500-3000 | MP89-15 | SP99-02 | |
| Power-Miser "M" | 6.1-9.27 (100-152) | 27-40 (100-152) | 2500-3000 (172-207) | 2500-3000 | MP92-05 | SP99-02 | |
| Power-Pro "M" | 6.1-9.27 (100-152) | 27-40 (100-152) | 2500-3000 (172-207) | 2500-3000 | MP89-15 | SP99-02 | |
| MLSM "Live Pak" | 6.1-9.27 (100-152) | 27-40 (100-152) | 2500-3000 (172-207) | 2500-3000 | MP97-06 | SP97-02 | |
| Vane Pumps |
A | .2-1.39 (3.3-22.8) | .86-6.0 (3.3-22.8) | 2000-2250 (140-160) | 1800-4200 | MP02-04 | N/A |
| B | 1.19-2.59 (19.5-42.4) | 5.0-11 (19-42) | 2000-2250 (140-160) | 1800-3600 | MP02-04 | N/A | |
| C | .66-6.10 (10.8-96.4) | 3-26 (10.8-96.4) | 2300-3500 (158-241) | 2500-2800 | MP02-05 | N/A | |
| D | 2.9-9.64 (47.5-158) | 12-42 (47.5-158) | 3000 (207) | 2200-2500 | MP02-05 | N/A | |
| C Quiet-Pak | .66-6.10 (10.8-96.4) | 3-26 (10.8-96.4) | 2300-3500 (158-241) | 2500-2800 | MP01-11 | N/A | |
| D Quiet-Pak | 2.9-9.64 (47.5-158) | 12-42 (47.5-158) | 3000 (207) | 2200-2500 | MP01-11 | N/A | |
| E | 8.07-13.08 (132-227) | 35-60 (132-227) | 3000 (207) | 2200 | MP02-05 | N/A | |
| Piston Pumps |
PV2 | 3.66-8.85 (60-145) | 19-38 (60-145) | 4600 (320) | 2200-2800 | MP98-03 | N/A |
| PVC | 2.00 (33) | 8.7 (33) | 3000 (207) | 3000 | MP98-03 | N/A | |
| PP | .732-2.01 (12-33) | 3.17-8.71 (12.33) | 5075 (350) | 2400 | MP01-02 | N/A | |
| PQ | 1.16-3.66 (19-60) | 5-15.8 (19-60) | 4350-5075 (300-350) | 1700-1800 | MP01-03 | N/A | |
| PR | 4.27-6.1 (70-100) | 18.5-26.4 (70-100) | 5075 (350) | 1600 | MP01-04 | N/A | |
| PR tandem (per section) |
2.5-3.11 (41-51) | 10.8-13.5 (41-51) | 4350 (300) | 1600 | MP01-06 | N/A | |
| PT | 2.62-4.88 (43-80) | 11.6-20.7 (43.80) | 4350-5075 (300-350) | 1800 | MP01-06 | N/A |
